Host customization
We can design compressors according to different media, gas volume, pressure and other parameters. We use imported frequency converters. We have experienced design team, super machine-added ability and neat staffing. ● Enterprises involved in the field include: petrochemicals, fertilizers, fine chemicals, steel mills, refineries, gas stations, blowing bottles, food, pharmaceuticals, etc. ●It can design and manufacture large and medium reciprocating compressors with various pressures of 32MPa and gas volume of 100m3/min. ● Seven-stage argon oil-free compressor, gas volume: 20m3/min, pressure 10MPa |  |
● Five-stage high-purity nitrogen oil-free compressor, gas volume: 14m3/min, pressure 11MPa
The independently developed HM series PET bottle blowing compressor is the crystallization of the technical advantages of Hengman Company. It has three technical advantages of oil-free lubrication, PEEK and gas valve, and the first domestic variable frequency control gas volume and self-made three wearing parts. The rare piston speed of 3.5-4m/s in China meets the characteristics of safe and reliable blow cylinder compressor with long operating cycle, which shows the advantages of high efficiency, environmental protection, energy saving and consumption reduction. The outlet pressure is 40 bar, the gas volume is from 20-80 m3/min, and the five main models are controlled by the inverter:
| model | Gas volume | Pressure bar | Using frequency conversion | PLC automatic control | Direct motor connection | Dimensions |
4M3.5-25/40-HW | 18-25 | 40 | √ | √ | √ | 5*3.5*2.9 |
4M6-35/40-HW | 25-35 | 40 | √ | √ | √ | 6*4.5*3.3 |
4M8-50/40-HW | 35-50 | 40 | √ | √ | Optional | 7*5.5*3.8 |
4M10-60/40-HW | 45-60 | 40 | √ | √ | Optional | 7.5*6.5*4 |
4M12-80/40-HW | 60-80 | 40 | √ | √ | Optional | 8*6.5*4.3 |
| ●Inertial force is properly balanced, stable operation, low vibration and low noise ●The compressor as a whole is in the field of view, easy to observe, operate, replace consumables and maintenance ● Consumable parts have large advantages, good functions, long continuous operation cycle, and meet the production process requirements. ●Frequency conversion technology to meet the gas supply demand ●Super large-scale test bench, can carry out factory operation test to ensure the quality of each equipment |
●The first domestic inverter compressor ● Cancel the gas volume adjustment mechanism, effectively adjust the supply and demand gas volume, save energy and reduce consumption ●The motor can be directly connected according to the needs of the user's site, and the energy saving can be maximized. ●Compressor level data acquisition, alarm record monitoring, adjust alarm value according to user needs, PLC+ large touch screen, easy and fast operation control | |
